Application:
Advantage:It is suitable for weaving various glass fiber cloths. High speed and stability.
Weaving scope:Electronic cloth, fishing rod cloth, heat insulation, fireproof, flame retardant cloth
Advantage:It is suitable for weaving various glass fiber cloths. High speed and stability.
Weaving scope:Electronic cloth, fishing rod cloth, heat insulation, fireproof, flame retardant cloth
● Technical parameter
Item
| Specification | Remark | |
Reed width | Reed width(cm) | 150.190. 210. | |
Fabric |
Material & weave | Electronic cloth, fishing rod cloth, heat insulation, fireproof, flame retardant cloth | |
Power
| Main power
| 2.2kw Power consumption is depend on reed width and shedding method. | |
Speed | Motor-belt pulley | RPM 600 650 700 800 | |
Weft insertion
| Weft selection | 1 2 | |
Magnetic valve | SMC Japan | 3 nozzle per valve | |
Feeder
| Vibration model | ||
Without WPS WPS | |||
1 2 | |||
Nozzle | Energy-saving nozzle | ||
Shedding
| Shedding method | Undermount cam | |
Heald frame | 1 2 4 6 | ||
Let off device | Mechanical type Electronic type | Single beam | |
Flange diameter | |||
Take up device | Take up | Electronic take up (ETU) Mechanical take-up(MTU) | |
Max cloth roll diameter | Ø1200mm(jumb batching motion) | ||
Beating | Roller beating system | Four-bar beating-up motion | |
Selvage | Leno gear selvage | ||
edge | Tuck-in device or leno selvage | ||
Cutter |
| ||
Lubrication |
| ||
Stop motion
| Weft stop | Reflective weft feeler
| |
Warp stop |
| ||
Control system | Inovance brand Made-in-China | With BaiNa-borad(data setting, automatic control,monitoring,self-diagnosis function, WPS interface) | |
Automation | Pick ending |
| |
Accessory
|
| 3000pcs | |
| 1:1.5 | ||
| 1:1.5 | ||
| 1:1 | ||
| 3000pcs |
